The sliding door systems are designed to bring continuity to the space making it possible to demarcate different spaces, while maintaining a strong sense of unity overall. Amid transparency, reflections, and colors, dynamic interiors relate to one another, with the design for space and furnishings constitute a whole. An overall vision that combines technological innovation with stylistic variety, with a view to creating spaces that are ever more in line with individual sensitivities. Aluminum and glass: two natural materials that are environment-friendly and always used for new aesthetic and functional solutions.
The extruded aluminum sections are made from 6060 and 6063 alloy composition, in order to fulfill system requirements and suitable for anodizing or painting.
GasketBoth static and dynamic gaskets are realized in EPDM (ethylene propylene diene monomer). The retention brushes are in high-density propylene with central water stripping.
AccessoriesPatented accessories, made with the best materials, have been studied for an easy, rational use. The hinges are Stainless Steel to take maximum load.
GlazingThe system can integrate glazed used from 6mm to 38mm thick glass. Glass blocking must be done through internal/external gaskets in EPDM. The possible infiltration water must be drained outwards, as in the system
Depth of outer Frames | 38 mm |
Depth of sash | 38 mm |
Application | Bed Room, living Rooms |
Glass | Minimum: 6 mm |
