Able 80 is a modular and innovative swing windows system which stands out for its thermal and acoustic performance. The system is a highly adaptable and flexible product with ease of maintenance.
The extruded aluminum sections are made from 6060 and 6063 alloy composition with polyamide strip, in order to fulfill system requirements and suitable for high thermal insulation and compatibility for anodizing or painting.
GasketBoth static and dynamic gaskets are realized in EPDM (ethylene propylene diene monomer). The retention brushes are in high-density propylene with central water stripping.
AccessoriesPatented accessories, made with the best materials, have been studied for an easy, rational use. The hinges are Stainless Steel to take maximum load.
GlazingThe system can integrate glazed used from 6mm to 38mm thick glass. Glass blocking must be done through internal/external gaskets in EPDM. The possible infiltration water must be drained outwards, as in the system.
Depth of outer Frames | 80 mm |
Depth of sash | 92 mm |
Application | Bed Room, living Rooms, Bath Room |
Glass | Minimum: 24 mm |
